Note 搭建维护小记 ¶
本文记录了在搭建 Note 时使用的技术栈,再此记录便于后续更新维护。
由于最近心血来潮,把整个 Note 的技术架构做了一次升级,花了巨大的时间做了很多对以前配置的兼容性更改,以更好的支持新 feature。 所以这次以后并不打算做进一步的升级了,除非是什么根本性的更新,之后可以目前版本的基础上自己进行开发更新降低兼容难度,而且可以更好的满足custom的需求。
基础配置 ¶
首先先把使用到的基础包总体列一下。
Package | Version | 备注 |
---|---|---|
mkdocs | 1.6.1 | Fork from Offical mkdocs |
mkdocs-material | 9.6.5 | Fork from Offical Material |
mkdocs-glightbox | 0.4.0 | Fork from Offical mkdocs-glightbox |
mkdocs-git-revision-date-localized-plugin | 1.3.0 | Fork from Offical mkdocs-git-revision-date-localized-plugin |
mkdocs-encryptcontent-plugin | 2.2.1 | Fork from TonyCrane |
mkdocs-changelog-plugin | 0.1.3 | Fork from TonyCrane |
mkdocs-heti-plugin | 0.1.6 | Fork from TonyCrane |
mkdocs-statistics-plugin | 0.1.4 | Fork from TonyCrane |
mkdocs-tikzautomata-plugin | 0.0.1 | Fork from TonyCrane |
mkdocs-toc-plugin | 0.0.2 | Fork from TonyCrane |
glightbox: 实现图片点击放大查看
git-revision-date-localized-plugin:能够根据 git log 自动跟踪文档修改和创建时间
encryptcontent-plugin:实现文档页面内容加密
changelog-plugin:好看的更新记录插件
heti-plugin:自动实现中西文之间的空格
statistics-plugin:实现所有文档内容字数等统计
tikzautomata-plugin:在 markdown 中直接编写 tikz 并嵌入 svg
toc-plugin:实现自定义的 table of content
首页 UI 配置 ¶
参照 pokemon-cards-css 项目,简单制作了卡片 UI,能够将就着看。
其他部分设计参考了鹤翔万里的笔记本
文档时间记录的额外配置 ¶
对于部分加密文件,其没有被 git 所记录,所以时间依靠手动更新,需要重写content.html
文件。
利用page.meta.data
和page.meta.revision_data
两个参数来手动指定创建时间和修改时间。
重写部分
{% if page and page.meta and (
page.meta.git_revision_date_localized or
page.meta.revision_date
) %}
{% if page and page.meta %}
{% if page.meta.hide and "date" in page.meta.hide %}
{% elif page.meta.data and page.meta.revision_data %}
<aside class="md-source-file">
<span class="md-source-file__fact">
<span class="md-icon" title="最后更新">
<svg viewBox="0 0 24 24" xmlns="http://www.w3.org/2000/svg"><path d="M21 13.1c-.1 0-.3.1-.4.2l-1 1 2.1 2.1 1-1c.2-.2.2-.6 0-.8l-1.3-1.3c-.1-.1-.2-.2-.4-.2m-1.9 1.8-6.1 6V23h2.1l6.1-6.1zM12.5 7v5.2l4 2.4-1 1L11 13V7zM11 21.9c-5.1-.5-9-4.8-9-9.9C2 6.5 6.5 2 12 2c5.3 0 9.6 4.1 10 9.3-.3-.1-.6-.2-1-.2s-.7.1-1 .2C19.6 7.2 16.2 4 12 4c-4.4 0-8 3.6-8 8 0 4.1 3.1 7.5 7.1 7.9l-.1.2z"></path></svg>
</span>
<span class="git-revision-date-localized-plugin git-revision-date-localized-plugin-custom">{{ page.meta.revision_data }}</span>
</span>
<span class="md-source-file__fact">
<span class="md-icon" title="创建日期">
<svg viewBox="0 0 24 24" xmlns="http://www.w3.org/2000/svg"><path d="M14.47 15.08 11 13V7h1.5v5.25l3.08 1.83c-.41.28-.79.62-1.11 1m-1.39 4.84c-.36.05-.71.08-1.08.08-4.42 0-8-3.58-8-8s3.58-8 8-8 8 3.58 8 8c0 .37-.03.72-.08 1.08.69.1 1.33.32 1.92.64.1-.56.16-1.13.16-1.72 0-5.5-4.5-10-10-10S2 6.5 2 12s4.47 10 10 10c.59 0 1.16-.06 1.72-.16-.32-.59-.54-1.23-.64-1.92M18 15v3h-3v2h3v3h2v-3h3v-2h-3v-3z"></path></svg>
</span>
<span class="git-revision-date-localized-plugin git-revision-date-localized-plugin-custom">{{ page.meta.data }}</span>
</span>
</aside>
{% else %}
{% include "partials/source-file.html" %}
{% endif %}
{% endif %}
{% endif %}
修复 enrypt-plugin ¶
后来发现新版本好像已经修了,不过问题不大
在使用加密插件的时候,通过使用以下配置来同时加密 toc
然而发现当输入正确密码后无法正确显示 toc,于是进一步调试发现 toc 部分并未被正确加密,而是单纯被设置为display: none
, 在 html 源码中能找到未加密的 toc 明文。继续阅读源码,可以发现在解密 js 中有如下代码。
if (html_item[i]) {
var parts = html_item[i].innerHTML.split(';');
// decrypt it
if (parts[0], parts[1], parts[2]) {
var content = decrypt_content(password_input.value, parts[0], parts[1], parts[2]);
};
if (content) {
// success; display the decrypted content
html_item[i].innerHTML = content;
html_item[i].style.display = null;
// any post processing on the decrypted content should be done here
};
}
其中content
有无内容决定了是否显示被隐藏的内容,但是由于之前加密中放的是明文内容,导致解密后的content==undefined
,所以导致了无法显示。
于是追本溯源,发现在原来的 encrypt-plugin 中有这样一段代码存在问题,并没有正确使用beatifulSoup
这个库来导致的。
item.contents = [
content for content in item.contents if content not in ['\n', ' ']
]
# Merge the content in case there are several elements
if len(item.contents) > 1:
merge_item = ''.join([str(s) for s in item.contents])
elif len(item.contents) == 1:
merge_item = item.contents[0]
else:
merge_item = ""
# Encrypt child items on target tags with page password
cipher_bundle = self.__encrypt_text_aes__(merge_item, str(page.password))
encrypted_content = b';'.join(cipher_bundle).decode('ascii')
# Replace initial content with encrypted one
bs4_encrypted_content = BeautifulSoup(encrypted_content, 'html.parser')
item.contents = [bs4_encrypted_content] # 这里未能正确使用
if item.has_attr('style'):
if isinstance(item['style'], list):
item['style'].append("display:none")
else:
item['style'] = item['class'] + "display:none"
else:
item['style'] = "display:none"
首先item
的类型是bs4.element.Tag
,我们可以知道它有一个content
属性用来存放其中存储的内容,在加密源码中我们可以发现,它直接对content
进行了赋值操作,这是一个有问题的操作,单纯的赋值并没有对 tree 进行任何改变,所以对最终的 html 没有任何影响。于是看一下tag
的源码
def clear(self, decompose=False):
"""Wipe out all children of this PageElement by calling extract()
on them.
:param decompose: If this is True, decompose() (a more
destructive method) will be called instead of extract().
"""
if decompose:
for element in self.contents[:]:
if isinstance(element, Tag):
element.decompose()
else:
element.extract()
else:
for element in self.contents[:]:
element.extract()
@string.setter
def string(self, string):
"""Replace this PageElement's contents with `string`."""
self.clear()
self.append(string.__class__(string))
可以发现对contents
的处理都是通过其他方式实现的,所以可以猜测为contents
可能只能算是个只读变量,后面继续深扒了append
,而它又是通过insert
,最终可以发现是在所有操作结束后把结果填入contents
中,因此验证了之前的猜测。
知道了原因,所以修复也很容易,只需要借用一下tag.string.setter
的方法,即可完成原有需求。
小结 ¶
一下子就写了这么点,其实也就为了记录一下这次的升级过程中遇到的一些问题,也不知道该写啥了。可能还有其他小问题忘了,想起来了再慢慢补上,后面要是又有什么新问题也能补上。
